OMRON Limit Switch

•

  Two-Circuit Limit Switch [WL-N/WL]

  OMRON

  The 2-circuit limit switch with variety of models that can be selected matching to the usage environment and application.

  [Features]
  · Circuit will break without fail by using 2-circuit double-break.
  · Structure suitable to IP67 due to O ring and/or cover seal.
  · Overseas approval corresponding to the machines for export approved by UL, CSA, TUV, EN/IEC, CCC.
  · Most suitable to machines for export.
  · Optimum high accuracy type in controlling the position is available in all types.
  · Movement till operation is less (about 5°) but repeatability is two times of standard type

  CAD ：

  2D / 3D

  Standard Price:	21,128 IDR-
  Days to Ship:	Same day or more

•

  Compact Sealed Switch [ZC-□55]

  OMRON

  Compact seal switch with high durability (10 million times), and high accuracy

  [Features]
  · Compact and high accuracy seal switch: Compact and high accuracy seal switch with high durability of 10 million times or more, and high repeatability due to built-in micro switch.
  · Fitting pitch same as Z type.
  · Power required for operation (OF) is less as compared to the general limit switch.
  · Operation display convenient for maintenance and inspection is also available.
  · Approved by EN(TüV), UL, CCC.

  CAD ：

  2D / 3D

  Standard Price:	329,803 IDR-
  Days to Ship:	Same day or more

•

  Safety Limit Switch [D4B-□N]

  OMRON

  Robust safety limit switch with metallic housing. Direct opening mechanism in both of slow action type, and snap action type

  [Features]
  · Direct opening mechanism (only at NC contact side) to separate contact at the time of fault in contact welding.
  · Safety of lever setting is achieved by using operation position display board and mechanism by which lever is interlocked.
  · Proper operation zone display mechanism is also available.
  · Moreover, changing of direction of lateral movement is also by one-touch.
  · Improvement in sealing property by strengthening the seal structure of head part (meets TÜ V: IECIP67, UL: NEMA3, 4, 4X, 6P,13).
  · Wide available temperature range of - 40 to +80°C.
  · Approved by UL, CSA, EN(TÜV), CCC

  CAD ：

  3D

  Standard Price:	762,300 IDR-
  Days to Ship:	Same day or more

•

  Small Limit Switch [HL-5000]

  OMRON

  Compact limit switch with high practicability in low price. For head, box and cover, an uneven interlocking method is used and thus robustness is maintained.

  CAD ：

  2D / 3D

  Standard Price:	475,714 IDR-
  Days to Ship:	Same day or more

•

  Small Safety Limit Switch [D4N]

  OMRON

  Safety limit switch standards. Enriched products provided globally

  CAD ：

  3D

  Standard Price:	209,833 IDR-
  Days to Ship:	Same day or more

•

  Small Solenoid Lock / Safety Door Switch [D4SL-N]

  OMRON

  General-purpose enclosed switch with high shut-off capacity and high durability
  [Features]
  · ZE, ZV, and ZV2 types have built-in Z type general-purpose basic switch.
  · Highly durable and has a large shutoff capacity.
  · There are three types of mounting methods: side, bottom and side diagonal, as well as abundant actuator types.
  · Connecting is easy since the terminal of the built-in switch is on the front when the cover is removed.
  · Models with ground terminals support CE Marking.
  · UL/CSA/CCC certified (contact the manufacturer for the certification format).

  CAD ：

  2D / 3D

  Standard Price:	574,239 IDR-
  Days to Ship:	Same day or more

•

  Small Safety Door Switch / Slide Key Unit [D4NS/D4NS-SK]

  OMRON

  Next generation safety door switch supporting multi-contact, man-hours saving and micro load

  [Features]
  · As regards the contact structure, in addition of the conventional 1NC/1NO, 2NC, three type of 2NC/1NO, 3NC are available.
  · M12 connector type easy to replace and saving man-hours is also released.
  · Standardized au clad contact with high contact reliability.
  · Supports both i.e. general load and micro load.
  · Metallic head variation

  CAD ：

  2D / 3D

  Standard Price:	447,193 IDR-
  Days to Ship:	Same day or more

•

  Small Limit Switch [D4C]

  OMRON

  Mainly standards with improved sealing properties

  CAD ：

  2D / 3D

  Standard Price:	292,413 IDR-
  Days to Ship:	Same day or more

•

  Flexible Rod Switch [TP70]

  OMRON

  [Features]
  · Easy input by hand while moving.
  · Hand-friendly plastic rod type.
  · One-way operation.
  · Provided with stopper that operates only by touching from one direction.
  · Yellow colored so that easy to understand for the operator from the color of main body.
  · Three types matching to the fitting place.
  · Series with emergency stop switch is also made.

  CAD ：

  2D

  Standard Price:	1,719,230 IDR-
  Days to Ship:	Same day or more

•

  Small Safety Limit Switch [D4F]

  OMRON

  World's smallest class. Safety limit switch

  [Features]
  · Limit switch with world's smallest direct opening operation mechanism (4 contacts).
  · Safety limit switch with high sensitivity.
  · Built-in switch available with 2 contacts/4 contacts.
  · An IP67 protective structure.
  · Compatible with EN115-1, EN81-1 and EN81-2 (slow-action type only.)
  · Approved by UL, EN(TÜV), CCC

  CAD ：

  3D

  Standard Price:	728,928 IDR-
  Days to Ship:	Same day or more

•

  Small Electromagnetic Lock Safety Door Switch [D4NL]

  OMRON

  Best selling, compact, multi-contact with variety of variations

  CAD ：

  2D / 3D

  Standard Price:	2,062,842 IDR-
  Days to Ship:	Same day or more

•

  Small Enclosed Switch [D4E-□N]

  OMRON

  Meets the needs such as light, thin, short and compact model, high durability and high seal with further improvement in performance of D4E.

  [Features]
  · Improved snap action property, high durability by changing lever ratio of spring of built-in switch board.
  · Excellent in dust resistance, oil resistance by using a cover for built-in switch.
  · Moreover, high durability of seal cap of plunger.
  · Connector system capable of reducing the maintenance time at the time of wiring (screw tightening terminals also available that one is accustomed to use)
  · Micro load type can be used in controlling electronic circuit by metal clad contacts.
  · Mold terminal type, mold terminal with operation display light type are also available in the spring tightening method.
  · EN(TÜV), U

  CAD ：

  2D

  Standard Price:	329,803 IDR-
  Days to Ship:	Same day or more

•

  Solenoid Lock / Safety Door Switch / Slide Key Unit [D4JL/D4JL-SK40]

  OMRON

  Lock Strength 3,000 N
  [Features]
  · Various monitoring patterns can be used thanks to 2 circuits + 2 contacts in the safety circuit.
  · It uses gold clad contacts as standard and supports both general load and micro load. The trap key type helps avoid the danger of being left behind within the fence.
  · A rear release button type that allows unlocking from the inside and egress even when locked within the fence.
  · Protection degree IP67.

  CAD ：

  2D / 3D

  Standard Price:	2,439,411 IDR-
  Days to Ship:	Same day or more

•

  Oil Resistant Limit Switch [D4ER-□N]

  OMRON

  The oil resistance of D4E-N has been further improved

  [Features]
  · It uses HNBR/fluororubber with excellent oil resistance and prevents ingress of cutting fluid from moving parts
  · Equipped with a fluorine resin cable that's resistant to cutting fluid
  · A lineup of easily wired connector types (Smart Click Connector)
  · The microload type can be used for electronic circuit control using gold clad contacts
  · EN (TÜV) Standards Acquired
  · The mounting pitch is the same as D4E
  · Protection Degree IP67G (JIS C 0920 Annex 1)

  CAD ：

  2D / 3D

  Standard Price:	842,986 IDR-
  Days to Ship:	Same day or more

•

  General-Purpose Enclosed Switch [ZE/ZV/ZV2/XE/XV/XV2]

  OMRON

  Built-in general-purpose basic switch Z.
  Side mounting type.

  [Features]
  · General-purpose seal switch with high durability and large breaking capacity.
  · ZE, ZV, ZV2 has built-in general-purpose basic switch Z.
  · High durability with large breaking capacity.
  · There are 3 mounting methods such as side mounting, bottom mounting and side diagonal mounting method with variety of actuators.
  · After removing cover, the terminal of built-in switch is on front surface and hence connection is easy.
  · The product with earth terminal supports CE marking.
  · Approved by UL, CSA, CCC (ask your manufacturer for information on approved models).

  CAD ：

  2D / 3D

  Standard Price:	303,877 IDR-
  Days to Ship:	Same day or more

•

  Compact Heavy Equipment Limit Switch [D4A-□N]

  OMRON

  Standards with improved sealing properties, shock resistance properties and strength tolerance

  [Features]
  · A double seal on the head, a complete gasket cover, and other features ensure a better seal.
  · Wide standard operating temperature range (-40 to +100°C: standard type).
  · Models with fluoro-rubber available for greater resistance to chemicals.
  · Block mounting method also reduces downtime for maintenance.
  · 4-circuit double-break models available for complex operations

  Standard Price:	924,233 IDR-
  Days to Ship:	Same day or more

•

  Semi-Compact Sealed Switch [D4MC]

  OMRON

  Seal switch with improved strength, dust proof property and drip proof property

  [Features]
  · Seal switch with high durability of 10 million times or more and high repeatability due to built-in micro switch.
  · Operation position is same as Z type in case of panel fitting type.
  · Possible to use in applications requiring more strength, dust proof properties and drip proof properties than micro switch.
  · Resin hardened mold terminals are also available.
  · Approved by UL, CCC

  CAD ：

  2D / 3D

  Standard Price:	212,143 IDR-
  Days to Ship:	Same day or more

•

  Compact Enclosed Switch [SHL]

  OMRON

  [Features]
  · Compact general-purpose horizontal type
  · Series of micro load types is also made.
  · Built-in coil spring system switch boasting high durability in robust, precise die-cast case.
  · Compact and can be used in applications wherein single usage of micro switch is very unsafe

  CAD ：

  2D

  Standard Price:	309,184 IDR-
  Days to Ship:	Same day or more

•

  Safety Door Switch [D4BS]

  OMRON

  Blocks the control circuit by directly opening the contact by using the operation key only used to open the protective door of machine tools

  [Features]
  · Approved by EN (TÜT) compliant to CE marking.
  · Approved by UL, CSA.
  · Direct opening of contact of switch at the time of opening protective cover by using the direct opening operation mechanism (only at NC contact side).
  · Approval of EN standard of direct opening operation is shown by mark on the switch.
  · Prevents error operation and fake operation by using exclusive operation key.
  · A wide temperature range of -40 to+80°C.
  · The protective structure of switch box is approved by IP67 (EN60947-5-1).

  Standard Price:	115,147 IDR-
  Days to Ship:	Same day or more

•

  Small safety door hinge door switch

  OMRON

  Compact safety hinge door switch made up of resin and supporting reduction in space of machine

  CAD ：

  3D

  Standard Price:	826,451 IDR-
  Days to Ship:	8 Day(s) or more

•

  Small Limit Switch [D4CC]

  OMRON

  Roller lever type with thickness of 16 mm. The cable connection is connector connection type with easy replacement of limit switch.

  CAD ：

  2D / 3D

  Standard Price:	610,527 IDR-
  Days to Ship:	Same day or more

•

  High Precision Switch [D5A]

  OMRON

  Detects the displacement of micron unit

  [Features]
  · High accuracy switch detecting micron displacement.
  · It can be used to detect cutting edge wearing such as drill, tool and to detect work source.
  · Excellent in wear resistance and usage of ceramic plunger not getting affected by changes in the temperature (in case of M5, M8, slim type).
  · Direct input to microcomputer and PC is possible.
  · Variety of connectors with operation display lamp available

  CAD ：

  2D

  Standard Price:	2,514,541 IDR-
  Days to Ship:	Same day or more

•

  Tactile Switch [D5B]

  OMRON

  For detecting object from multiple directions

  [Features]
  · Multi-application tactile switch to detect the object from multiple direction.
  · Slow actions switch structure
  · Contact with metallic plating and high contact reliability due to micro load.
  · Direct input to microcomputer and programmable controller is possible.
  · Three type of M5, M8, M10 with small outer diameter.
  · Panel fitting system with easy fitting

  CAD ：

  2D / 3D

  Standard Price:	394,044 IDR-
  Days to Ship:	Same day or more

•

  Slim Type Safety / Door Switch [D4GS-N]

  OMRON

  [Features]
  · IP67 compliant thin door switch.
  · Slim type with 17 mm width (3 contacts).
  · Possible to use on front or back surface due to reversible structure.
  · Built-in switch available with 2 contacts and 3 contacts.
  · Operation key uses a structure to absorb vibration and shocks using rubber in fitting hole.
  · Protective structure IP67

  CAD ：

  3D

  Standard Price:	122,811 IDR-
  Days to Ship:	Same day or more

•

  Limit Touch Switch [NL]

  OMRON

  Possible to detect just by touching slightly.

  [Features]
  · Possible to detect just by touching slightly and operation displayed by light emitting diode.
  · High accuracy position detection with very less hysteresis movement is possible in order to operate at the moment of contact.
  · Micro displacement and light weight objects can be detected without requiring operation power.
  · Operation is easy to confirm by light emitting diode.
  · Many functions are possible by combining with sensor controller type S3D2 (DC type)

  CAD ：

  2D / 3D

  Standard Price:	3,975,265 IDR
  Days to Ship:	Same day

•

  Multi-Pull Limit Switch [VB]

  OMRON

  VB type appeared with new form. Improvement in strength and sealing property of head with integrated head box. Drastic improvement in mechanical durability.

  [Features]
  · Possible to use in various types of machine tools and sequence controlling such as transfer/machine.
  · Possible to remove oil/water though entered into the plunger as oil filter is provided.
  · Approved by EN/IEC (only with earth terminal), and approved by CCC.
  · The product with earth terminal supports CE marking.

  CAD ：

  3D

  Standard Price:	2,019,719 IDR-
  Days to Ship:	8 Day(s) or more

•

  Small Enclosed Switch VE

  OMRON

  [Features]
  · Compact and light weight seal switch.
  · Excellent dust proof and mechanically strong V type compact basic switch by sealing it in die-cast case.
  · In case of cams/arms types and cams/roller arms type, the position of arm can be set to 360° random position.

  CAD ：

  2D

  Standard Price:	577,348 IDR-
  Days to Ship:	Same day or more

•

  Compact Insertion Switch

  OMRON

  Compact and high accuracy seal switch

  [Features]
  · Compact and high accuracy seal switch with high durability of 10 million times or more, and high repeatability due to built-in micro switch.
  · Fitting pitch same as Z type.
  · Power required for operation (OF) is less as compared to the general limit switch.
  · Operation display convenient for maintenance and inspection is also available.
  · Approve by EN(TÜV), UL, CCC

  Standard Price:	374,437 IDR
  Days to Ship:	8 Day(s)

•

  Solenoid Lock / Safety Door Switch [D4BL]

  OMRON

  After the cutting tool stops due to the inertia of the machine, unlock the protective cover using the controller signal, pushbutton switch, etc.
  [Features]
  · The mechanical lock automatically engages when the operation key is inserted. The mechanism releases the lock only when voltage is applied to the solenoid, realizing high safety.
  · It has acquired EN (TÜV) Standards compatible with CE Marking.
  · UL/CSA/CCC certified.
  · The direct circuit opening mechanism (NC contact side only) is used to open the switch contacts when opening the protective cover. The direct circuit opening certification by EN standards is displayed on the switch cover.
  · The release key handles maintenance power outages (power supply failures).
  · The main body is made of robust and strong aluminum die-cast, and the inside of the box has protection degree IP67, UL, CSA Type 6P, 13.
  · Also equipped with two conduit ports in horizontal and vertical directions.
  · A series of display unit types that show operation status at a glance and adjustable operation keys that support double doors.
  · By changing the direction of the head in 4 directions, the operation key can be inserted in 4 directions.

  CAD ：

  2D / 3D

  Standard Price:	3,499,957 IDR-
  Days to Ship:	8 Day(s) or more

•

  Small Limit Switch [DV4]

  OMRON

  Standard Price:	301,429 IDR
  Days to Ship:	Same day

Loading...
